Specifications:
| Syringe Size | 10, 20, 30, 50/60 ml |
| Applicable Syringe | Compatible with syringe of any standard |
|
Flow Rate |
Syringe 10 ml: 0.1-400 ml/h
Syringe 20 ml:0.1-600ml/h ＜100 ml/h in 0.1ml/h increments Syringe 30 ml:0.1-900ml/h ≥100 ml/h in 1ml/h increments Syringe 50/60 ml: 0.1-1300ml/h |
|
Bolus Rate |
Syringe 10 ml: 400 ml/h
Syringe 20 ml: 600 ml/h Syringe 30 ml: 900 ml/h Syringe 50/60 ml: 1300 ml/h |
| Anti-Bolus | Automatic |
| Accuracy | ±2% (mechanical accuracy ≤1%) |
|
Infusion Mode |
Flow rate: ml/min, ml/h Time-based
Body weight: mg/kg/min, mg/kg/h, ug/kg/min, ug/kg/h etc. |
| KVO Rate | 0.1-1 ml/h (in 0.1 ml/h increments) |
|
Alarms |
Occlusion, near empty, end program, low battery, end battery,
AC power off, motor malfunction, system malfunction, reminder alarm, pressure sensor error, syringe installation error, syringe drop off |
|
Additional Features |
Real-time infused volume, automatic power switching,
automatic syringe identification, mute key, purge, bolus, anti-bolus, system memory |
| Drug Library | Available |
| Occlusion Sensitivity | High, medium, low |
| Power Supply, AC | 110/230 V (optional), 50/60 Hz, 20 VA |
| Battery | 9.6±1.6 V, rechargeable |
| Battery Life | 7 hours at 5 ml/h |
| Working Temperature | 5-40℃ |
| Relative Humidity | 20-90% |
| Atmospheric Pressure | 860-1060 hpa |
| Safety Classification | Class Ⅱ, type CF |
