Caractéristiques
• Le G-206 est équipé d’oculaires à grand champ.
• La source lumineuse est réglable en continu avec une lampe halogène.
• Le corps principal est en alliage d’aluminium et la structure est stable.
• Grâce à l’excellent système optique, il peut obtenir un champ large, un contraste net et une vue confortable.
Model | G-206 |
Observation tube | Binocular head inclined at 45˚ |
Interpupillary distance | From 55-75mm |
Focusing | Coaxial focusing knob, coarse focusing range is 15mm and fine focusing is graduated in increment of 2.5μm |
Stage | Mechanical stage, size 120 x 125mm with moving range 35 x 75mm |
Eyepiece | WF10X/18 |
Objective | Achromatic 4X, 10X, 40X (spring), 100X (spring) oil |
Condenser | N.A. 1.25 Abbe condenser with iris diaphragm and filter holder |
Illumination | 6V15W halogen lamp with adjustable light intensity |
Power supply | 110/220V switchable |
Standard accessories | Dust cover, blue and green filters, backup lamp, plano-concave mirror |
Optional accessories | WF10X/18 eyepiece with 10/100mm scale, WF15X eyepiece, 20X objective |
Voir la Fiche technique
