DESCRIPTION
300 Tests/Hour, Double Reagents

Multifunctional precision sampling probe
- External & internal mirror polish, external & internal probe washing
- Dedicated sampling probe equipped with sensitive liquid sensor, timely feedback of reagent & sample residuals
- Collision protection, automatic probe depth adjusting

Excellent mixer design
- Teflon coating mixer. No water dropping(reducing carry-over)
- Excellent mixing effect with standard mixing procedure

Reagent tray & Sample tray;
- 70 reagent positions,70 sample positions
- Non-stop cooling system with peltier pad inside, 24 hours 2℃-14℃
- Bar code reader(optional)

Reaction tray
- 90 reaction cuvettes
- Reaction volume as low as 150μl
- Stable & accurate temperature (37±0.1℃)for reaction

Washing systerm
- 3*5 steps automatic washing
- Efficient cleaning to ensure accurate results and reliable diagnnosis
Advanced operating system
- User friendly software interface simple, easy-to-operation
- Sample automatic dilution(decrease, increase, normal)
- Reaction result automatic checking and warning, calibaration result automatic checking, warning alarm log
- Linear & nonlinear calibration, Multi-points calibration up to 8 points
- Quality control apply to westgard, L-T plot, cumulative
SPECIFICATIONS
General information | |
Machine type | Random access, open reagent & locked reagent (optional) |
Test speed | Constant 300 tests/hour (Mono reagent or double reagent) |
Test principle | Colorimetric method, turbidimetry |
Test method | 1 point end, 2 point end, Fixed-Time, Kinetics |
Calibration type | Linear & nonlinear |
Sample unit | |
Sample tray | 70 sample positions |
Sample tube | Micro cup & test tube & blood collection tube can be used. (φ12 -13 )mm * (25 -100 )mm |
Sample volume | 2-30µL, step by 0.1µL |
Sample probe | Liquid surface detection, timely tracking for liquid volume. Collision avoidance |
Sample barcode | Sample barcode reader (optional) |
Reagent unit | |
Reagent tray | 70 reagent positions, Non-stop cooling system with peltier pad inside, 24 hours 2°C-14°C, open system, could accept any reagent |
Reagent volume | 20-300µL, step by 1 µL |
Reagent needle | Liquid surface detection,timely tracking for liquid volume.Collision avoidance. |
Regent barcode | Regent barcode reader (optional) |
Reaction unit | |
Reaction tray | 90 reaction cuvettes, new amorphous optical plastics reaction cups, |
